YANTAI STARK INSTRUMENT CO., LTD.

Multi-parameter measurement, temperature compensation and automatic range conversion are achieved thanks to

the high-performance CPU chip, high-precision AD conversion technology and SMT pasting technology,

resulting in high precision and repeatability.

Reliability: Touch keys, no switch knob or potentiometer.

Alarm: Isolated output of alarming signals, discretionary setting of upper and lower thresholds for alarming, and

lagged cancellation of alarming.

Isolated current output: Discretionary setting of upper and lower thresholds of current corresponding to the

Conductivity.

1.Display mode: LED (nixie tube) display, high brightness, striking to the eye and highly readable, long viewing

distance.

2.Measuring range: (0~20000)μS/cm; temperature: 0~99.9℃

3.Electrode constant: 0.01~20μS/cm    (Electrode K=0.01)

   0.1~200μS/cm   (Electrode K=0.1)

                                   1.0~2000μS/cm  (Electrode K=1.0)

                                   10～20000μS/cm (Electrode K=10.0)

4.Resolution: 0.001μS/cm, 0.1℃

5.Electrode constant: 0.001-15.0 cm^-1 (depending on the software)

6.Temperature compensation range: Automatic 0-99.9℃,

manual 0-99.9℃ (25℃ Conversion)

7.Accuracy: ±1.0%F.S., ±0.3℃

8.Isolated current output: 4~20 mA(load <750Ω)

9.Alarming relay: AC220V, 3A, isolated output of alarming signals

10.Communication interface: Isolated RS485(optional)

11.Power supply: AC220V, 50Hz ±1Hz  DC24V(optional)

12.Protection grade: IP65

13.Working conditions: ambient temperature: 0-60℃; relative humidity≤90%

14.Power-down memory: >10 years;

15.Weight and dimension: 0.8kg, 96 × 96 ×110 mm

16.Dimension of the hole: 92 * 92mm; Installation mode of secondary meter: Drilling type

17.Installation mode of electrode: Flow-through/immerged/flanged/pipe-based

18.Standard configuration: One secondary meter and one electrode
